RFID Vehicle Barrier Gate Parking Management Systems with RS485 Communication Module

Basic Information
Place of Origin: China
Brand Name: WEJOIN
Certification: CE, ISO,
Model Number: WJDZ601
Minimum Order Quantity: 1set
Price: negotiation
Packaging Details: Carton package
Delivery Time: 3-15 days depending on the quantity
Payment Terms: T/T, Western Union
Supply Ability: 5, 000 set/month
Detail Information
Material: Aluminum Color: Optional
Speed: 3s, 6s Max Boom Length: 6m
Loop Detector: Optional RS485 Communication Module: Optional
High Light:

automatic barrier gate system

,

vehicle access control barriers


Product Description



RFID Vehicle Barrier Gate Parking Management Systems with RS485 Communication Module





Quick Detail:



  1. Name: Vehicle Barrier Gate
  2. Application: Parking System
  3. Speed:4/6 second
  4. Protection Grade:IP44
  5. Rated Power:80W
  6. Feature: Auto-closing
  7. Certificate:CE, ISO,
  8. Voltage:AC220V, AC110V





Description:



Model Selection and Differences



Model Boom Shape Max Boom Length Speed
WJDZ60116 Straight boom 4.5m 6 seconds
WJDZ60113 Straight boom 4m 3 seconds
WJDZ60126 90 degree, Articulated boom 4m 6 seconds
WJDZ60123 90 degree, Articulated boom 3m 3 seconds
WJDZ60136 180 degree, Articulated boom 4m 6 seconds
WJDZ60133 180 degree, Articulated boom 3m 3 seconds
WJDZ60146 Two-level, fence boom 3.5m 6 seconds
WJDZ60156 Three-level, fence boom 3m 6 seconds





Functions & Features:



1. RS485 communication module (optional)
2. Advanced manual release
3. Thermal radiates rapidly, no thermal protection
4. Special art and craft makes out the most modernized and fashionable housing

5. Auto closing,Adopts the 3rd generation WEJOIN machine core
6. Boom can rise and fall on left/right side by setting on the same machine
7. No need to change the balance spring when changing the booms
8. Safety photo electricity limit switch
9. Supports the infrared photocell for anti-bumping function (optional)
10. Supports the external and internal vehicle loop detector (optional)
11. Die-cast aluminum alloy machine core and advanced double-stage driving motor effectively solve the problem of mechanism block up





Specifications



Name Barrier Gate Application Parking System
Speed 3/6 second Max Boom Length 6m
Power Supply AC220V/AC110V Rated Power 120W
Motor Rotational Speed 1400rpm Protection Degree IP44
Working Temperature -35℃~75℃ Humidity ≤90%
Remote Control Distance ≤50m Boom Dimension 45*100mm
Net Weight 39kg Gross Weight 44kg
Certificate CE/ISO Boom Type Octagonal boom





Applications:



Barrier Gate with aluminum alloy housing screen uses the third generation motor. It is stable and has long service life performance, running one million times. And the barrier can work with parking system very well, and can be used in door and outdoor.







Why to choose WEJOIN  Vehicle Barrier Gate?



1. Barrier Gate is suitable for vehicle flux control of the access. This barrier gate is unique for its good looking, and full molding design for all main parts. Die-cast by aluminum alloy, the barrier gate is anticorrosive. Compact design of machine core adopts big reduction ratio technology, come true machine core more compact and smart appearance. Unique transformed boom can rise and fall on left/right sides under the direction. Only need one standard of balance spring can suit to all length of the booms, no need to change the spring.

2. WEJOIN has sub-companies to produce and process almost accessories. Besides standard producing, at the same time, we offer OEM service

3. Special barrier core makes its installation direction adjustable. Also The barrier works well with the barrier can be changed booms with different length, without changing its spring. The barrier works well with infrared photocells, loop detectors, the boom will automatically rise up when it meets pedestrian and vehicles. Manual release device can operate the barrier when power failure.

4. Barrier Gate uses the third generation motor. It is stable and has long service life performance,normal life span is one million times.





RS4845 Communication Module
