| Place of Origin: | China |
|---|---|
| Brand Name: | WEJOIN |
| Certification: | ISO |
| Model Number: | WJTY301 |
| Minimum Order Quantity: | 1set |
| Price: | Negotiation |
| Packaging Details: | WOODEN |
| Delivery Time: | 3-7DAYS |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 3000 SETS |
| Close Opening Time: | 0.5s | Housing Finished: | Stainless Steel |
|---|---|---|---|
| Flap Speed: | Adjustable | Flap Material: | Oganic Glass |
| Infrared Photocell: | Yes | Customized Products: | Yes |
| Safety: | Yes | Opening/closing Time: | Adjustable |
| High Light: | security turnstiles,half height turnstile |
||
Widen Lane 900mm SS Automatic Systems Turnstiles Electro - Mechanical Design
Function:
1. With function of self-examine and alarm, it is convenient for maintenance and use.
2. Be able to program running status by the small keyboard in the main board
3. Flap door will stop move when it is being blocked, which prevent pedestrians from being nipped and from hurt.
4. Light and sound alarm is generated when the illegal invasion and the tail followed.
5. Arms are automatically locked until opening signal is received.
6. Arms synchronization (adjustable).
7. Automatically reset function: It will automatically lock if the pedestrian hasn’t pass through the channel in the pre-set time after the opening. The passing time is adjustable.(default time is 10sec.)
8. Automatically open the gate when power off and automatically close when power on.
9. Several readers devices are attachable.(IC, ID access control, fingerprint access control, barcode ticket access control, facial identification access control, time attendance machine est.)
10. One direction or bi-direction is optional.
11. It can be directly controlled and managed by remote control.
Products Series:
|
Model |
WJTY201 |
WJTY301 |
WJTY311 |
|
Material of Housing |
304 Stainless Steel |
||
|
Material of Flap Door |
Organic Glass, Resin, or PVC |
||
|
Dimension of housing |
1200*270*1000 |
1450*315*1020 |
1400*305*1020 |
|
Thickness of housing |
1.5mm |
||
|
Max Width of Passage |
600 |
900 |
900 |
|
Net weight |
70kg |
140 kg |
85 kg |
|
Normal Life Span |
3 millions times |
||
|
Communication Interface |
Standard RS485(distance less than 1200 meters) |
||
|
Transit speed |
30-40 persons/min |
||
|
Power supply |
220V±10%, 110± 10% |
||
|
Frequency |
50/60HZ |
||
|
Working voltage of motor |
DC24V |
||
|
Time for opening or closing |
1s |
||
|
Starting time after power on |
3s |
||
|
Input interface |
Dry contact signal or +12Vor pulse signal with width more than |
||
|
Transit speed |
25~32 persons/min |
||
|
Working temperature |
-10°C~50°C |
||
|
Working environment |
Indoor / Outdoor (Shelter) |
||
|
Relative humidity |
≤95%, no condensation |
||
