| Place of Origin: | Shenzhen,China |
|---|---|
| Brand Name: | WEJOIN |
| Certification: | ISO 9001:2008,CE, |
| Model Number: | WJTS111 |
| Minimum Order Quantity: | 1set |
| Price: | negotiation |
| Packaging Details: | Export Wooden Case |
| Delivery Time: | 3-15 days depending on the quantity |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 1,000 set/month |
| Manual,Semi Or Full-automatic: | Full-automatic | Material Of Housing: | 304 Stainless Steel |
|---|---|---|---|
| Thickness Of Housing: | 1.5mm | Max Load-bearing Of Pole: | 80kg |
| Rotaing Direction: | Double Direction | Power Supply: | 220V±10%, 110V±10%, 50/60HZ |
| High Light: | pedestrian barrier gate,security entrance gates |
||
Flexible Double Tripod Turnstile Gate Waist Height With Dc Motor For Museum
Quick Detail:
Name；Automatic Tripod turnstile
Driving Motor:DC Motor
Power Supply:220V±10%, 110V±10%
Frequency:50/60HZ
Rotating Direction:Double Direction
Housing material:Stainless Steel 304/ Iron with Powder
Function and Features:
1. Electromechanical integration design, unique rotation pan with special technical design, steady and reliable self-locking mechanism, precise gear structure integrated with the housing
2. All the system runs stable with little noise and no mechanical impact
3. It can self-check and alarm which will be make it convenient to use
4. Several ways of working molds can be chosen at your request
5. It can work bi-direction, or one direction permitted, one forbidden, or one direction charged, one for free, and all the working molds can be set by the buttons in the main control board
6. Beam falling and lifting can be controlled in far distance so to satisfy the special requirement of the users and the request of fire protection
7. Beam can be lifted and fall when electricity is cut-off
8. It has the standard electrical interface which can be connected with various kinds of reader and writer equipment
9. So all the functions can be realized in one integration machine and can be controlled and managed by the computer in the far distance
10. The number of the persons who have passed by can be counted automatically which can also be displayed in LED
11. Direction-guide lights are in the turnstile to tell you which direction can go or which cannot
12. You can set the function with or without card-reading memory according to your requirement
13. The number of the persons who can pass by the turnstile can be set to meet the requirement of some special occasions
14. The arm will automatically reset when the passengers don't pass within valid time, canceling this access authority
Specifications:
|
Model |
WJTS122 |
WJTS110 |
WJTS112 |
WJTS111 |
|
Manual, Semi or Full-automatic |
Full-automatic |
|||
|
Material of Housing |
304 Stainless Steel |
Iron with Powder |
||
|
Length of Pole (out of housing) |
490mm |
|||
|
Dimension of Housing |
420×380×1000 |
1235×280×1000 |
1235×280×1000 |
420×380×1050 |
|
Thickness of Housing |
1.50mm |
|||
|
Net Weight |
50kg |
70kg |
70kg |
45kg |
|
Max Load-bearing of Pole |
80kg |
|||
|
Driving Force of Pole |
3KG |
|||
|
Rotating Direction |
Double Direction |
|||
|
Power Supply |
220V±10%, 110V±10% |
|||
|
Frequency |
50/60HZ |
|||
|
Input Interface |
DC12V electrical leveel signal, more than 100ms, |
|||
|
Rated Power |
50W |
|||
|
Driving Motor |
DC Motor |
|||
|
Working Voltage of Motor |
DC12V |
|||
|
Transit Speed |
30~40 persons/min |
|||
|
Working Temperature |
－40°C~55°C |
|||
|
Working Environment |
Indoor / Outdoor (Shelter) |
|||
|
Relative Humidity |
≤95% |
|||
Applications:
The tripod turnstiles can be used in places such as restaurants, hotels, office buildings, museums, gyms, clubs, metros, bus stations,supermarket, high class communities, intelligent buildings, hotels, subway stations ,school and other high level venues, ect.
After-sale Service:
1 year warranty
Lifetime Service with charge accordingly
Preview Detail
1. Barrier Gate core: Unique design and precise artistic
2. Arm:length is 490mm with 304 stainless steel
3. High-technology control board
4. Safer packing
