Parking Lot Boom Vehicle Barrier Gates , Automatic Gate Barrier System Steel Housing

    • Parking Lot Boom Vehicle Barrier Gates , Automatic Gate Barrier System Steel Housing
    • Parking Lot Boom Vehicle Barrier Gates , Automatic Gate Barrier System Steel Housing
    • Parking Lot Boom Vehicle Barrier Gates , Automatic Gate Barrier System Steel Housing
  • Parking Lot Boom Vehicle Barrier Gates , Automatic Gate Barrier System Steel Housing

    Product Details:

    Place of Origin: China
    Brand Name: WEJOIN
    Certification: CE, ISO,
    Model Number: WJDZ501

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiable
    Packaging Details: Carton Package 111*40*50
    Delivery Time: 3-7 working days after payment received
    Payment Terms: T/T, Western Union
    Supply Ability: 5000 sets per month
    Contact Now
    Detailed Product Description
    Material Of Housing: Steel Speed Of Motor: 1s,1.8s,3s,6s
    Max Boom Length: 6m Standard Color: Orange & White; Blue&white
    Standard Package: Carton Package Boom Type: Straight Boom; Folding Boom; Fence Boom

    AC220V High Speed Parking Barrier Gate for Toll Way Gate with Blue&White Color Housing





    Application



    Suitable for indoor as well as outdoor parking area
    Parking lots, toll gate, goods yard, railway crossing, commercial premises, apartment block access shopping malls, hospitals, stadiums, business centers,etc.





    Technical Specification



    Description

    Parameter

    Working Temperature

    -40℃~+75℃

    Voltage

    220V±10%, 110V±10%, 50/60HZ

    Rated power

    80W

    Relative humidity

    ≤90%

    Remote control distance

    ≥30m

    Net weight

    60kgs

    Arm Speed

    1s, 1.8s, 3s, 6s

    Max boom length

    6 meters





    Ordering Information





    Model No.

    Open/Close Speed

    Max Boom Length

    Boom Type

    WJDZ50116

    6 seconds

    6m

    Straight boom

    WJDZ50113

    3 seconds

    4.5m

    Straight boom

    WJDZ50111

    1 second

    3m

    Straight boom

    WJDZ50126

    6 seconds

    5m

    90 degree, Articulated boom

    WJDZ50123

    3 seconds

    3m

    90 degree, Articulated boom

    WJDZ50136

    6 seconds

    5m

    180 degree, Articulated boom

    WJDZ50133

    3 seconds

    3m

    180 degree, Articulated boom

    WJDZ50146

    6 seconds

    4.5m

    Two-level, fence boom

    WJDZ50156

    6 seconds

    4m

    Three level, fence boom





    Functions & Features



    1. New design with LED display screen, available for many kinds of fonts, such as Chinese, English and with Red & Green lights, when the boom open up to 90 degrees, green light flashing,, when the boom in the process of operation, red light flashing.

    2. Safe---the barrier will automatically go back when meet obstacles during closing.

    3, Swing Out---Arm will swing out when hit directly by vehicle (only 1 second model ) to avoid further damage on the vehicle.

    4. Clutch key can be used to release the clutch when power off.

    5. Fan cooling machine reduces the motor temperature by high frequency using, and never get over-heated. Unique temperature calefaction design for low temperature using prevents freezing in cold weather.

    6. Exactitude aluminum alloy die-casting motor base reduces the noise and joint abrasion to prolong the barrier gate working life.

    7. Thimble type motor worm design for preventing plugging up in using.

    8. Balance spring--- no noise and easy adjusting.

    9. Double limit ways (electronic limit and motor sensor memory limit) for boom rising and falling.



    Parking Lot Boom Vehicle Barrier Gates , Automatic Gate Barrier System Steel HousingParking Lot Boom Vehicle Barrier Gates , Automatic Gate Barrier System Steel Housing
