Fashion Entrance Swing Barrier Gate Customized Barcode Reader / Scanner

Basic Information
Place of Origin: China
Brand Name: WEJOIN
Certification: CE,ISO
Model Number: WJTB301
Minimum Order Quantity: 1set
Price: negotiation
Packaging Details: Wooden package
Delivery Time: 1-15 Days Depend on Quantity
Payment Terms: T/T, Western Union
Supply Ability: 50set / week
Detail Information
Housing Material: 304 Stainless Steel With Special Processing Material Of Swing Door: Glass
Dimension Of Housing: 1500*120*1009mm Dimension Of Mechanism: Φ108*450mm
Width Of Passage: 500mm Trade Term: EXW, FOB, CIF
Motor Material: Steel And Aluminum Alloy Transit Speed: 20~30 Persons/min
High Light:

speed gate systems

,

pedestrian gate access control


Product Description



Fashion Entrance Swing Barrier Gate Customized Barcode Reader / Scanner





Automatic Glass Lane Pedestrian Swing Gate for High - Level Aress with read card





Technical data



Material of Housing 304 Stainless Steel with special processing
Material of Swing Door Glass
Dimension of housing 1500*120*1009mm
Mechanism dimension ø108*450mm
Max Width of Passage 500mm
Motor Material steel and aluminum alloy
Transit Speed 20-30 persons/min
Power Supply AC 220V±10%,AC 110V±10%
Frequency 50/60Hz
Working voltage of motor DC24V
Time for opening or closing 1sec
Starting time after power on 3sec
Working temperature -25℃ ~ +55℃
Working environment Indoor/Outdoor (with shelter)
Relative humidity ≤95%, no condensation




Housing Dimension:

Fashion Entrance Swing Barrier Gate Customized Barcode Reader / Scanner 0

MACHINE CORE

Fashion Entrance Swing Barrier Gate Customized Barcode Reader / Scanner 1



Functions and features
1. a compact electro-mechanical design with an exquisite rotating plate and self-lock mechanism.
2. automatic detection for malfunction
3. input interface for dry contact and switch signal available for Simple integration of all common access control system.
4. adjustable auto-delay closing
5. infrared photocells for safety access
6. alarm for unauthorized access and no access against passenger flow
7. anti-reversing passing
8. auto closing when power on
9. auto open and free access when power off
10. adjustable access directions
11. emergency interface available
12. traffic light indicating passenger access





Product detail

Fashion Entrance Swing Barrier Gate Customized Barcode Reader / Scanner 2

Fashion Entrance Swing Barrier Gate Customized Barcode Reader / Scanner 3
