Automatic Access Control Barriers Parking Toll System High Speed IP44 Protection

    • Automatic Access Control Barriers Parking Toll System High Speed IP44 Protection
    • Automatic Access Control Barriers Parking Toll System High Speed IP44 Protection
    • Automatic Access Control Barriers Parking Toll System High Speed IP44 Protection
  • Automatic Access Control Barriers Parking Toll System High Speed IP44 Protection

    Product Details:

    Place of Origin: China
    Brand Name: WEJOIN
    Certification: CE,ISO,
    Model Number: WJDZ820

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: negotiation
    Packaging Details: Carton,wooden box
    Delivery Time: 1-20 days
    Payment Terms: T/T,L/C,Western Union
    Supply Ability: 10000 units/month
    Trade Terms: EXW,FOB,CIF
    Contact Now
    Detailed Product Description
    Voltage: 220v 110v Power: 80w
    Protection Grade: IP44 Motor Voltage: 220v
    Running Time: 1s,3s,6s



    Custom Ticket Dispenser access control barrier Parking Lot Arm Gate





    Applications:





    Barrier Gate with rubber boom uses the third generation motor. It is stable and has long service life performance, running one million times. Its housing is made of galvanized steel with 1.5mm thickness, and painted, so that the barrier can be used in door and outdoor.





    Quick Detail:





    1. Name: Boom barrier gate
    2. Application: Ticket dispenser
    3. Speed:3/6 second
    4. Feature: Loop detector
    5. Rated Power:80W
    6. Certificate:CE, ISO,
    7. Net Weight:50KG
    8. Voltage:AC220V, AC110V





    Description:





    Model Selection and Differences





    Model(WJDZ)



    Item

    820-13 820-16 820-26 820-36 820-46 820-56
    Opening Time 3S 6S
    Boom Type Straight

    Articulated

    90 degree

    Articulated

    180 degree

    Fence

    Two-level

    Fence

    Three level

    Boom Length 3m 6m 5m 5m 5m 5m
    Voltage 220V/110V
    Remote control distance 30m≤L≤100m
    Protection Grade IP44
    Working Temperature -35℃ - +60℃
    Rated Power 80w





    Functions & Features:





    1. Open the barrier gate by motor wheel when power off and automatic locking when power on

    2. Balanced boom running with a motor transmission of cranks and shafts

    3. Boom with protective rubber band

    4. Interface for traffic light

    5. Infrared photocells interface is available

    6. Loop detector interface is available

    7. Well-integrated with car parking system equipments, with wire control (push button)

    8. Offering dry contact signal for car parking system (COM, NC, NO)

    9. Auto-reverse when the boom meets obstruction

    10. Auto-delay when closing (adjustable)

    11. Remote control frequency: 315 MHz, 418MHz, 433MHz

    12. Remote control to operate the barrier gate







    Specifications





    Model WJDZ820
    Working Temperature -35℃~+60℃
    Voltage 220V±10%, 110V±10%, 50/60HZ
    Rated power 80W
    Relative humidity ≤90%
    Remote control distance ≥30m
    Net weight 50kgs
    Speed 1.5S, 3S, 6S
    Max boom length 6 meters



    Communication with customers





    Q: There is no reaction on the motor when pressing the remote controller buttons,why?

    A:(1)Please check whether the power is supplied to the barrier gate orr not

    (2)Please check whether the fuse id burnt out or not

    (3)Please check whether the code both in the remote controller and the control board are accordant or not



    Q: Sometimes, Why the barrier boom would open automatically?

    A: Please check if the limit switch is on the right position; if not, please adjust the Limit Switch. Please refer to last page of Barrier Gate Manual. Or you can adjust the adjusting screw. And the last step is to check the intensity of the spring.



    Q: What's WEJOIN monthly production capacity for barrier gate?

    A: 10000 units.



    Q: What’s the remote control distance?

    A: In general, most of WEJOIN 418 remote control can cover 100 meters, but it is not safe and stable to control the barrier gate from 100 meters away. WEJOIN recommends using the remote control within 30 meters or 50 meters.





    Why to choose WEJOIN 110/220v Barrier Gate For Ticket Dispenser?





    1. The barrier core is special and main parts are aluminum alloy casting. The barrier gate will automatically reverse when the boom meets the obstruction. The barrier works well with infrared photocells, loop detectors, the boom will automatically rise up when it meets pedestrian and vehicles

    2. Barrier Gate uses the third generation motor. It is stable and has long service life performance, running one million times. Its housing is made of galvanized steel with 1.5mm thickness, and painted, so that the barrier can be used in door and outdoor.

    3. Barrier Gate adopts the latest mold casting design, without clutch device. Its machine core adopts connecting rod structure mainly comprised with worm wheel, worm and crank arm. The barrier gate runs stably, and is conveniently maintained.

    4. WEJOIN has sub-companies to produce and process almost accessories. Besides standard producing, we offer OEM service in the meanwhile.
