| Place of Origin: | China |
|---|---|
| Brand Name: | WEJOIN |
| Certification: | CE,ISO, |
| Model Number: | WJDZ102 |
| Minimum Order Quantity: | 1 unit |
| Price: | negotiation |
| Packaging Details: | Carton,wooden box |
| Delivery Time: | 3-7 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000 Units / Month |
| Speed: | 1S; 1.8S; 3S; 6S | Color: | Orange |
|---|---|---|---|
| Motor Material: | Die-casting Aluminum Alloy | Housing Material: | Steel |
| Max Boom Length: | 8 Metes | COM Interface: | RS485 |
| High Light: | Higher Stability Car Parking Gate,Die Casting Car Parking Gate,Auto Reversing Toll Barrier Gate |
||
Higher stability Automatic Car Parking Gate Barrier System Toll Barrier Gate
Toll Barrier Straight boom installation
Step 1. Fix the boom holder pressboard on the boom with 2pcs of M12*70mm hexagon screw.
Step 2. Press the board by hand, then lift up the boom vertically and install it on the boom holder.
Step 3. Install the flat washer, spring washer, and M12 nut on the screw in turn, and fix the screw with a wrench.
Barrier Gate Technical Data
1. Working temperature (motor): -35℃~ + 70℃
2. Power supply: 220V±10% 50/60 Hz; 110V±10% 50/60 Hz
3. Net weight: 60 Kg
4. Rated power: 120W
5. Relative Humidity: 30%~80%, No condensation
6. Distance of remote control: L≥30M
Parking Barrier Spring selection
Balance spring dimension 50*440mm
The Innerspring has a rubber cover and PVC tube.
The innerspring dimension is 3.0*26mm
It is innerspring if the boom length is 5.5m-6m.
There are three small compression springs inside with rubber cover to each other to make the boom is more reliable and safe as well as to reduce the fatigue of the spring. The PVC is to fix the innerspring, then install in the large spring of 6.4mm
| number | Boom length | Spring parameter(mm) | Hole position(1or 2) |
| 1 | 2.5 <L<3.5 | D=4.5 | Hole2 |
| 2 | 3.5≤L≤4.0 | D=5.5 | Hole1 |
| 3 | 4.0<L<5.5 | D=6.5 | Hole2 |
| 4 | 5.5≤L≤6.0 | D=6.5 | Hole1 |
The data is according to the boom produced in our company.
