Custom Ticket Dispenser access control barrier Parking Lot Arm Gate
Quick Detail:
Description:
Model Selection and Differences
Model(WJDZ)
Item | 820-13 | 820-16 | 820-26 | 820-36 | 820-46 | 820-56 |
Opening Time | 3S | 6S | ||||
Boom-Type | Straight | Articulated 90 degree | Articulated 180 degree | Fence Two-level | Fence Three-level | |
Boom Length | 3m | 6m | 5m | 5m | 5m | 5m |
Voltage | 220V/110V | |||||
Remote control distance | 30m ≤ L ≤100m | |||||
Protection Grade | IP44 | |||||
Working Temperature | -35℃ - +60℃ | |||||
Rated Power | 80w |
Functions & Features:
1. Open the barrier gate by the motor wheel when power off and automatic locking when power on
2. Balanced boom running with a motor transmission of cranks and shafts
3. Boom with a protective rubber band
4. Interface for a traffic light
5. Infrared photocells interface is available
6. Loop detector interface is available
7. Well-integrated with car parking system equipment, with wire control (push button)
8. Offering dry contact signal for car parking system (COM, NC, NO)
9. Auto-reverse when the boom meets the obstruction
10. Auto-delay when closing (adjustable)
11. Remote control frequency: 315 MHz, 418MHz, 433MHz
12. Remote control to operate the barrier gate
