| Place of Origin: | China |
|---|---|
| Brand Name: | WEJOIN |
| Certification: | CE,ISO |
| Model Number: | WITB106 |
| Minimum Order Quantity: | 1PC |
| Price: | negotiation |
| Packaging Details: | wooden box |
| Delivery Time: | 5-10 days |
| Payment Terms: | Telex Release |
| Supply Ability: | 50PCS/week |
| High Light: | speed gate systems,pedestrian gate access control |
||
|---|---|---|---|
Functions and features
1.a compact electro-mechanical design with unique drive and a self-lock mechanism
2. automatic detection for malfunction
3. input interface for dry contact and switch signal connection
4. adjustable auto-delay closing
5. infrared photocells for safety access
6. alarm for unauthorized access and no access against passenger flow
7. anti-reversing passing
8. auto closing when power on
9. auto open and free access when power off
10. adjustable access directions
11. emergency interface available
12. traffic light indicating passenger access
Description:
1. WEJOIN swing barriers have automatic detection for malfunctions, which will be convenient for customer to maintain and operate.
2. Secondly, WEJOIN swing barriers have a compact electro-mechanical design with unique drive which and a self-lock mechanism to ensure product durability and silent operation
3. Thirdly, WEJOIN swing barriers have input interface that are available for dry contact and switch signal connections. So that customers can integrate the swing barrier with different system, like card reader, ticket system, token system etc.
4. Fourthly, WEJOIN swing barriers input interface available for dry contact and switch signal connection
5. Fifthly, WEJOIN swing barriers have audible and visual alarm in case of unauthorized access, which can strengthen the entrance security.
6. Lastly,WEJOIN swing barriers can be integrated with fire control device, which allow the release on emergency for security consideration.
Technical data
1. Housing dimension: bridge type bevel angle 1400*270*1000mm
2.Flap arm length: 275mm
3. Max arm width: 900mm
4.Housing material: stainless steel 304
5. Power supply/frequency: AC220V±10%, 50HZ, AC110±10%, 60HZ
6. Drive motor: 12V direct current brush motor
7..Flow speed: 25~30/minute
8.Input interface: +5V electric level signal or >100ms impulse signal, drive current >10mA, dry contact (COM NO).
9. Opening and closing time: 0.5 minute
10. Power on and reset time: 3s
11. IP protection degree: IP 32
12. Working environment:
13. Inner and outer (with shelter)
