Rubber boom automatic parking gate high speed DC brushless servo motor
WJCB02H boom barrier gate is a universal vehicular barrier gate which designed for heavy traffic management and large commercial applications. Durable finishing, reliable moment engine and multiple features make our barrier gates versatile solution for 24/7 use in heavy vehicle traffic flow.
Functions & Features
1. DC permanent magnet synchronous motor(PMSM),servo control.
2. Superior performance,equivalent to the main motor of the CNC machine tool and the electric vehicle motor, it has high control precision, high torque density, good torque balance, low power consumption, high efficiency, less heat and low noise.
3. Bi-direction boom holder design: left-installation and right-installation can be exchanged easily and quickly.
4. Electronic clutch design: more convenient to unclck or lock the motor when power off.(patented technology)
5. Three tension spring crank transmission design, for more stable and reliable structure.(patented technology)
6. No limit switch design, accurate encoder detection, detecting boom position when power on. And open/close speed is adjustable.
Technical Data
Input Voltage:AC 220V±10%, AC110V%,50/60HZ
Motor Voltage:DC310V
Enclosure Rating: IP54
Working Temperature: -35°C~+85°C
MTBF:10000000 times
Duty Cycle:100%
Traffic Flow Application:24 hours uninterrupted operation
Max Motor Power:300W
Max Motor Speed:90r/min
Max Torque: 480N.m
CB02H Series Boom Length and Speed Selection
|
Model |
WJCB02H |
||||
|
Running Speed |
0.9s~5s |
5s |
5s |
5s |
5s |
|
Boom Type |
Straight |
90° Folding |
180° Folding |
2 Fence |
3 Fence |
|
Max Boom Length |
3.5m~6m |
5m |
4m |
4.5m |
4m |
This Parking Barrier Gate provides a secure and convenient solution of stopping unauthorized vehicle or giving access to authorized vehicle, for parking lots with high traffic flow such as toll gate, shopping center, exhibition center, hospitals, airport etc.
