Photoelectric Dectection entrance gate security systems With Soft - tart
Quick Detail:
Name;Automatic Tripod turnstile
Power Supply:220V±10%, 110V±10%
Housing material:Stainless Steel 304/ Iron with Powder
Rotating Direction:Double Direction
Frequency:50/60HZ
Driving Motor:DC Motor
Application: Bus station
Function and Features:
1. Special wheel mechanism is used here to realize the function of fixing and also unfixing all the parts of the turnstile
2. The system runs steadily with low noise
3. Direction-guide lights are in the turnstile to tell you which direction can go or which cannot
4. Several ways of working molds can be chosen at your request
5. It can work bi-direction, or one direction permitted, one forbidden, or one direction charged, one for free, and all the working molds can be set by the buttons in the main control board
6. Beam falling and lifting can be controlled in far distance so to satisfy the special requirement of the users and the request of fire protection
7. It can self-check and alarm which will be make it convenient to use
8. It has the standard electrical interface which can be connected with various kinds of reader and writer equipment
9. So all the functions can be realized in one integration machine and can be controlled and managed by the computer in the far distance
10. The number of the persons who have passed by can be counted automatically which can also be displayed in LED
11. Beam can be lifted and fall when electricity is cut-off
12. You can set the function with or without card-reading memory according to your requirement
13. The number of the persons who can pass by the turnstile can be set to meet the requirement of some special occasions
14. After reading the card, if the person who punched the card does not pass it within the set time, then this chance to access will be canceled, and the set time can be changed according to your request
Specifications:
Model |
WJTS122 |
WJTS112 |
WJTS110 |
WJTS111 |
Manual, Semi or Full-automatic |
Full-automatic |
|||
Material of Housing |
304 Stainless Steel |
Iron with Powder |
||
Thickness of Housing |
1.50mm |
|||
Dimension of Housing |
420×380×1000 |
1235×280×1000 |
1235×280×1000 |
420×380×1050 |
Length of Pole (out of housing) |
490mm |
|||
Net Weight |
50kg |
70kg |
70kg |
45kg |
Max Load-bearing of Pole |
80kg |
|||
Driving Force of Pole |
3KG |
|||
Rotating Direction |
Double Direction |
|||
Power Supply |
220V±10%, 110V±10% |
|||
Frequency |
50/60HZ |
|||
Working Voltage of Motor |
DC12V |
|||
Rated Power |
50W |
|||
Driving Motor |
DC Motor |
|||
Input Interface |
DC12V electrical leveel signal, more than 100ms, |
|||
Transit Speed |
30~40 persons/min |
|||
Working Temperature |
-40°C~55°C |
|||
Working Environment |
Indoor / Outdoor (Shelter) |
|||
Relative Humidity |
≤95% |
Applications:
The tripod turnstiles can be used in places such as restaurants, hotels, office buildings, museums, gyms, clubs, metros, bus stations, high class communities, intelligent buildings, hotels, subway stations and other high level venues, ect.
