High SpeedTripod Turnstile Gate entry systems access control barriers 25 - 32 Person / Min

Basic Information
Place of Origin: Shenzhen,China
Brand Name: WEJOIN
Certification: ISO 9001:2008,CE,
Model Number: WJTS110
Minimum Order Quantity: 1set
Price: negotiation
Packaging Details: Export Wooden Case
Delivery Time: 3-15 days depending on the quantity
Payment Terms: T/T,Western Union
Supply Ability: 1,000 set/month
Detail Information
Transit Speed: Stainless Steel 304 Length Of Pole: 490mm
Relative Humidity: ≤95% Working Environment: Indoor / Outdoor (Shelter)
Driving Force: 3KG Rotating Direction: Double Direction
High Light:

pedestrian barrier gate


entrance gate security systems


High Speed Tripod Turnstile Gate

Product Description


High Speed turnstile entry systems access control barriers 25 - 32 Person / Min



Quick Detail:



  • Name;Automatic Tripod turnstile
  • Frequency:50/60HZ
  • Housing material:Stainless Steel 304/ Iron with Powder
  • Rotating Direction:Double Direction
  • Driving Motor:DC Motor
  • Application: Resident area
  • Power Supply:220V±10%, 110V±10%



Function and Features:




1. All the functions can be realized in one integration machine and can be controlled and managed by the computer in the far distance
2. All the system runs stable with little noise and no mechanical impact
3. Special wheel mechanism is used here to realize the function of fixing and also unfixing all the parts of the turnstile
4. Several ways of working molds can be chosen at your request
5. It can self-check and alarm which will be make it convenient to use
6. Beam falling and lifting can be controlled in far distance so to satisfy the special requirement of the users and the request of fire protection
7. Beam can be lifted and fall when electricity is cut-off
8. It has the standard electrical interface which can be connected with various kinds of reader and writer equipment
9. The working molds can be set by the buttons in the main control board:two-way passing or one-way passing and the other direction prohibited.
10. The number of the persons who have passed by can be counted automatically which can also be displayed in LED
11. Direction-guide lights are in the turnstile to tell you which direction can go or which cannot
12. You can set the function with or without card-reading memory according to your requirement
13. The number of the persons who can pass by the turnstile can be set to meet the requirement of some special occasions
14. After reading the card, if the person who punched the card does not pass it within the set time, then this chance to access will be canceled, and the set time can be changed according to your request






Manual, Semi or Full-automatic Full-automatic
Material of Housing 304 Stainless Steel Iron with Powder
Thickness of Housing 1.50mm
Dimension of Housing
(L×W×H mm)
420×380×1000 1235×280×1000 1235×280×1000 420×380×1050
Length of Pole (out of housing) 490mm
Net Weight 50kg 70kg 70kg 45kg
Max Load-bearing of Pole 80kg
Driving Force of Pole 3KG
Rotating Direction Double Direction
Working Environment Indoor / Outdoor (Shelter)
Input Interface DC12V electrical leveel signal, more than 100ms,
or DC12V impulse signal driveing current, more 10mA
Working Voltage of Motor DC12V
Rated Power 50W
Driving Motor DC Motor
Power Supply 220V±10%, 110V±10%
Transit Speed 30~40 persons/min
Working Temperature -40°C~55°C
Frequency 50/60HZ
Relative Humidity ≤95%







The tripod turnstiles can be used in places such as restaurants, hotels, office buildings, museums, gyms, clubs, metros, bus stations, high class communities, intelligent buildings, hotels, subway stations and other high level venues, ect.



After-sale Service:



1 year warranty

Lifetime Service with charge accordingly



Detail Preview:



  1. Barrier Gate core:delicate and small
  2. Arm:concise and convient
  3. High-technology control board
  4. Orderly and tidy workshop
  5. Safer packing

High SpeedTripod Turnstile Gate entry systems access control barriers 25 - 32 Person / Min 0
