Stainless Steel Full - auto Access Control Flap Barrier Gate With Double Channel

Basic Information
Place of Origin: China
Brand Name: WEJOIN
Certification: ISO
Model Number: WJTY201
Minimum Order Quantity: 2pcs
Price: Negotiation
Packaging Details: Wooden box
Delivery Time: 5-15 days
Payment Terms: T/T, , Western Union
Supply Ability: 200PCS/week
Detail Information
Housing Material: SST 304 Gate Length: 300mm
Passsage Wideth: 600mm Wing Material: Arylic
Package: Wooden Transit Speed: 30~40/min
High Light:

security turnstiles


optical turnstile

Product Description


Stainless Steel Full - auto Access Control Flap Barrier Gate With Double Channel


Product Description:


Integrating mechanism, electronics and micro-processor advanced technologies.The flap barrier is a improvement of intelligent tripod turnstiles.Equip various card-reading machines with hi-performance security protection SW to realize real-time warning and clever LED counter display guide passers .it balance pedestrian intelligent control and management.


Flap turnstile designs with tailored stainless steel make its elegance-looking,durable and anti-oxidation .Considering unique requests,we built-in standard electrical interface to best-fit customer easier using magnetic card,barcode,ID&IC cards integrated


This system provides civilized,well-organized pass management and meantime its prohibit illegal persons entry&out .


Functions & Features:


1. Self-checking function.
2. Working types:
2.1,bi-direction card reading; direction card reading and another prohibited;
3. Automatic turnstiles arm drop automatically when power off ;Arm recover its position automatically when power on.
4. Arm open&close time can be set by user in control boards
5. Manager can set pass time in control boards.
6. Flap barrier automatic alarm when illegal pass until passenger get an authorized card.
7. Human safe: optical & mechanical anti-impact.Optical sensor detect passenger position.100% avoid passenger hurt during in passing . If arm meets any obstacle, arm stop working immediately .
8.LED display passengers numbers.
9. Direction display guide passenger go or stop.
10. Control software regulate authorized passengers numbers.
11. Stable running with low- noise.




Model WJTY202
Cabinet dimension 1200mm(L)×270mm(W)×1000mm(H)
Stretching-out flap length 275mm
The max lane width 600mm
Cabinet material 304 stainless steel
Power supply AC220V±15%, AC110V±15%
Motor voltage DC24V (brush motor)
Access device input voltage dry contact or 12V electrical level signal or >100ms 12V impulse signal or driving current >10mA
Max flow rate 30~40 people per minute
Flap opening/closing time 1 sec
reset time when power on 3 sec
protection grade IP32
working environment outdoors (with shelter) and indoors.
working temperature -10°C~50°C
