Face recognition access control security flap barrier turnstile gate
Flap Barrier Gate Functions & Feature:
1. Using frequency conversion technology, which realizes running speed adjustment, to meet different access requirements and have a better experience.
2. Mechanical transmission parts are precisely made of high-strength plastic with pure mode design, which improve the
accuracy of spare parts and assembly, with more compact operation, smaller operation gap, and longer service life.
3. The exquisite product design, not only meets the longer life service, but also ruduce the difficulty of the maintenance, and ensures the traffic capacity of high pedestrian volume area under quick overhaul, maintenance and repair situation.
Flap Barrier Troubleshooting and Solutions
A. Flaps don’t stop in the limit position when open or close.
It might be the malfunction of limit switch, the loose or displacement of the limited switch can’t sense the flap to the limit position. User can adjust the position of the limited switch to renovate.
B: Single wing opens or both wings opens, and alarming” didi”.
Single wing opens, check the control board of the abnormal side, whether the switch protection is on, the fuse burn out or not. Switch power is abnormal or not.
If both wings open, check the power supply in the main motor side is normal or not, whether the switch protection is on, the fuse burn out or not, switch power is normal or not.
C. Flaps don’t open after power-off
Check the back-up batteries (lead-acid batteries) connection and voltage.
Speed Gate Standard package items
| NO. | name of parts | model | unit | quantity |
| 1 | Motor | set | 1 | |
| 2 | Cabinet | set | 1 | |
| 3 | Control panel | piece | 1 | |
| 4 | Card reader board | piece | 2 | |
| 5 | Traffic lights board | 2 | ||
| 6 | Switch Power Supply | piece | 1 | |
| 7 | Lead-acid batteries | 12V 1.2Ah | piece | 1 |
| 8 | Mounting bolt | M14*150 | piece | 4 |
| 9 | Instruction manual | copy | 1 | |
| 10 | Warranty card | copy | 1 |
