| Place of Origin: | CHINA |
|---|---|
| Brand Name: | WEJOIN |
| Certification: | CE ISO SGS |
| Model Number: | SCB02 |
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Packaging Details: | carton |
| Delivery Time: | 12 working days after payment received |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 10000 sets/month |
| Boom Type: | Straight Round Boom | Housing Color: | Gold |
|---|---|---|---|
| Application: | Parking Lot | Speed: | 0.3 Seconds MAX |
| MTBF: | 8,000,000 Times | Arm Material: | Aluminum Alloy |
| High Light: | SCB02 electric car park swing gate,car parking sliding gate Aluminum alloy,Straight round boom barrier gate |
||
No spring and Round Hollow-out design DC Variable-Frequency Barrier Gate
Boom Barrier Brief Introduction
1. The cabinet is round hollow-out design, with smooth lines and intuitive movement process.
2. Equipped with carbon fiber foam round boom, to effectively protect the vehicle.
3. Large LCD screen display, English visual menu, easy function selection and debugging.
4. Support external radar, coil, infrared anti-smashing function, built-in DC 12V power output, can be used for external radar power supply.
5. Support RS485 communication or RS485 off-line connection.
6. DC12V power supply is optional.
Parking Barrier Common Malfunctions and Solutions
| Malfunction Phenomenon | Possible Causes | Solution |
| The swing direction of the boom does not match the actual direction | The motor rotation direction setting is wrong | Refer to 2.1 to set the rotation direction of the master and slave motors |
| The boom is automatically lifted up after falls to the horizontal position | The retraction value of the main motor 4.5 in the closing to limit position is too large, or the mechanical limit adjusting bolt in the closing direction is extended to too much | Reduce the retraction value of the main motor 4.5 in the closing to limit, or readjust the mechanical limit adjusting bolt |
Barrier Gate Technical Data
1. Working temperature (motor): -35℃~ + 70℃
2. Power supply input voltage: AC110±10%, AC220V±10%
3. Controller input voltage: DC24V±10%, 10A
4. Motor power: up and down power 180W; horizontal power 60W
5. Relative Humidity: 30%~80%, No condensation
6. Distance of remote control: L≥30M
7. Running Speed: 0.3 seconds MAX
8. MTBF: 8,000,000 times
