Specifications
|
Model |
WJTY301 |
|
Cabinet dimension |
1715mm(L)×315mm(W)×1020mm(H) |
|
Stretching-out flap length |
440mm |
|
The max lane width |
900mm |
|
Cabinet material |
cold rolled steel & aluminum alloy |
|
Power supply |
AC220V±15%, AC110V±15% 50/60Hz |
|
Motor voltage |
DC24V (brush motor) |
|
Access device input voltage |
dry contact |
|
Max flow rate |
30~40 people per minute |
|
Flap opening/closing time |
0.5s ~ 1s |
|
reset time when power on |
2s |
|
protection grade |
IP32 |
|
working environment |
outdoors (with shelter) and indoors. |
|
working temperature |
-25°C ~ +50°C |
Features&Functions
1. Operational mode can be set up through the built-in menu on the control board.
2. Audible and visual alarm in case of unauthorized access.
3. RS232 and LAN sockets are available to connect the computer.
4. The design is of integration of machinery and electronic structure, with special drive style and reliable
machinery auto locking solution, precise worm gear, and cabinet composite structure.
5. Malfunction self-detection. Which is easy for operation and maintenance.
6. Available for two-way traffic lights, which can prompt the state---pass or no-entry.
7.Auto reset function, after the flap open if no pedestrian passes in a fixed time, the system will cancel the order and the auto-reset time is adjustable.
8. Flaps open when power off, and auto-close when power on.
