|Motor Type:||DC 12V||Protection Degree:||IP32|
|Housing Material:||304 Stainless Steel|
pedestrian barrier gate,
security entrance gates
Functions & Features
1. Full-automatic type
(1). Stainless steel Housing.
(2). Bi-direction pass.
(3). Arms auto drop when power off.
(4). Arms auto rise up when power on and auto stop on obstacle.
(5). Traffic light indicator.
(6). Wingen 26/Dry contact, is compatible with smart card for access control.
(7). Photoelectric inspection.
(8). If the passenger does not pass in valid time, the passage will be locked up. And the valid passing time can be set up by operator.
(9). Passenger counters (optional).
2. Semi-automatic type
(1). Auto-drop-arm function: the middle arm can drop down automatically (default) (or free passing) when the power is off.
(2). Emergency-escape function: the middle arm will drop down automatically by pressing the emergency button which can be remote-controlled whether the power is on or not.
(3). Structure has no motor.
(4). Both directions can be set as controlled mode or free mode.
(5). NO mode & NC mode can be switched over by users easily & freely.
(6). Self-recovery function: the machine will recovery automatically with invalid counting if passage is not completed within pre-set time (5 seconds default, adjustable by software).
(7). With interface of relay switch (the dry contact signal or +12V electrical level signal or DC12V pulse signal of pulse width ≥ 100ms, driving current ≥ 10mA), compatible with all kinds of access controllers.
(8). Each machine can be set by Physical Address (Optional).
(9). Equipped with free control software for man-machine interface & control command SDK.
3. Manual Type
(1). Arms can only rotate by single direction, but the direction can be changed easily inside.
(2). Structure has no electric devices.
