| Place of Origin: | China |
|---|---|
| Brand Name: | WEJOIN |
| Certification: | ISO,CE |
| Model Number: | WJTY601 |
| Minimum Order Quantity: | 1unit |
| Price: | negotiation |
| Packaging Details: | Wooden box |
| Delivery Time: | 10-30 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 50PCS/week |
| Wing: | Organic Glass | Function: | Anti-collision And Crashworthy |
|---|---|---|---|
| Advantage: | High Quality, Service & Factory Price | Operation: | Bi-direction |
| Usage: | Metro Station, Office, Library, Hotel | Trade Terms:: | EXW,CIF |
| High Light: | High Gloss Flap Barrier Gate,Servo Motor Flap Barrier Turnstile,High Gloss Flap Barrier Turnstile |
||
High-gloss 304 stainless steel housing servo motor flap barrier gate
Flap Barrier Functions & Features:
1. The design is of integration of machinery and electronic structure, with a special drive style, stable and reliable machinery auto-locking solution, precise worm gear, and cabinet composite structure.
2. Malfunction self-detection, which is easy for operation and maintenance;
3. Operational mode can be set up through the built-in menu on the control board;
4. Infrared photocells for anti-clamping;
5. Flap auto-reversing when meeting exterior force;
Flap Barrier Gate Technical Data:
|
No. |
Item |
Data |
|
1 |
Working Temperature |
-25℃～+70℃ |
|
2 |
Input Voltage of Power Supply |
AC110/220V±10% |
|
3 |
Input Voltage of Controller |
DC24V ±10% |
|
4 |
Working Voltage of Motor |
DC24V |
|
5 |
Motor Power |
50W |
|
6 |
Relative Humidity |
90% (no condensation) |
|
7 |
Material of Cabinet |
304 stainless steel |
|
8 |
Width of Passage |
600mm (a pair) |
|
9 |
Opening & Closing Speed |
0.2~1 seconds adjustable |
|
10 |
MTBF |
10,000,000 times |
Troubleshooting and Solutions
A. Partial or whole system is no power when power-on
Check the plug and wire to make sure no connection problem. Check the fuse of the control board to make sure no damage.
B. No flap opens and no reaction after input of the open signal
Check the indicator of the control board and make sure it can receive the open signal. Make sure the open signal wire is connected and no damage to the fuse.
