Smooth Traffic Flow in Parking Lot Intelligent Car Park Barrier Gate with Advanced Technology and 6m Telescopic Boom

Intelligent Car Park Barrier Gate with Advanced Technology and 6m Telescopic Boom for Smooth Traffic Flow

Automatic Barrier Functions and Features

1. The barrier gate is highly compatible with car parking system equipment, enabling integration through wire control. However, it is crucial to note that the control signal must be a dry contact signal. This well - integrated design allows for a unified management system, where the barrier gate can be coordinated with other parking system components such as ticket dispensers, payment terminals, and access card readers.

2. There is an interface provided for the traffic light, with a dry contact output. It is important to ensure that the traffic light used with this interface has a current draw of less than 10A. This interface allows for the synchronization of the barrier gate's operation with traffic lights, optimizing the flow of traffic and enhancing overall safety at the access point.

3. The barrier gate offers a signal of its limit status for the car parking system, with outputs for COM (common), NC (normally closed), and NO (normally open). These status signals can be used by the parking system to monitor the position of the barrier gate accurately, enabling better control and management of the parking facility. For example, the system can know if the gate is fully open, fully closed, or in an intermediate position.

4. The barrier gate comes with an auto - closing function, which can be adjusted from 3 seconds to 30 seconds. By default, this function is turned off at the factory. This adjustable auto - closing feature provides users with the flexibility to set the time interval according to their specific needs, whether it is for security reasons, traffic flow optimization, or energy conservation.

Common Malfunctions and Solutions

-Motor works but there is no reaction on the barrier arm

1. Check up the power supply and the fuse.

2. Check if the remote controller matches the radio receiver;or check up the battery inside and then change it if it is lack of power.

3. Check whether there is disturbance or not.

4. Check up the condition of photocell and loop detector.

Boom Barrier Technical Data
