Home /Products/Non-Spring Barrier Gate/Non-Spring Barrier Gate with 304 Stainless Steel Housing and 1.8s to 6s Operating Time for Vehicle Control

Non-Spring Barrier Gate with 304 Stainless Steel Housing and 1.8s to 6s Operating Time for Vehicle Control

1 set
MOQ
negociate
Price
Non-Spring Barrier Gate with 304 Stainless Steel Housing and 1.8s to 6s Operating Time for Vehicle Control
Features Gallery Product Description Request A Quote
Features
Specifications
Operating Time: 1.8s~6s
Boom Type: Straight Folding Fencing
Housing Material: 304 Stainless Steel
Color: Gold
Application: Parking Lot
Warranty: 1 Year
Basic Infomation
Place of Origin: CHINA
Brand Name: WEJOIN
Certification: CE ISO SGS
Model Number: E40
Payment & Shipping Terms
Packaging Details: carton
Delivery Time: 3-5 working days
Payment Terms: T/T,Western Union
Supply Ability: 10000 sets/month
Product Description
NonSpring Barrier Gate DZE4 Model
Straight Boom 3 to 6 Meters | Quick Speed 1.8 to 6 Seconds | Perfect for Vehicle Barrier Control Systems
DZE4 Boom Barrier Basic Features
Springless Design for Maintenance-Free Operation
DZE4 adopts a non-spring mechanical structure, eliminating the need for traditional spring balancing and mechanical leveling adjustments.
  • No spring fatigue or breakage risk
  • Reduced mechanical maintenance requirements
  • Stable operation throughout the product lifecycle
Flexible Communication and System Integration
The barrier gate supports various communication methods for intelligent parking and access control applications.
Communication Options:
  • RS485 communication
  • RS485 offline connection
The RS485 interface enables barrier gate control, status monitoring, and synchronized operation of multiple devices.
Optional DC24V Power Supply
DZE4 supports an optional DC24V power supply configuration, providing flexible power options for different project requirements.
Adjustable Boom Length and Opening Speed
To meet different installation environments, DZE4 supports multiple boom configurations.
Configuration Options:
  • Boom length: 3m to 6m
  • Closing time: 1.8s to 6s
The flexible configuration allows adaptation to different lane widths and traffic flow requirements.
High Safety Design During Power Failure
The boom structure is designed to remain securely positioned during power interruption.
Safety Feature:
  • The boom does not drop when power is disconnected
  • Helps prevent unexpected falling accidents
  • Improves safety in daily operation
Quick Operation Parameter Selection
Left-installed Right-installed
1: Straight boom/folding Boom 3M 4: Straight boom/folding Boom 3M
2: Straight boom/folding boom 3.5M 5: Straight boom/folding boom 3.5M
3: Straight boom/folding boom 4M 6: Straight boom/folding boom 4M
7: Straight boom≥4.5M/folding boom≥4M/fence boom 8: Straight boom≥4.5M/folding boom≥4M/fence boom
Common Malfunctions and Solutions
Malfunction: The controller displays IDLE
Possible Cause A: The motor sensor plug is not plugged in.
Solution: Insert the motor sensor plug well.
Possible Cause B: Motor sensor failure.
Solution: Replace the motor.
Malfunction: The controller resets when the barrier gate is running
Possible Cause A: Short circuit inside the motor.
Solution: Measure the resistance of each two wires (white, yellow and red) of the motor phase line by a multimeter, to check if the resistance numbers are the same.
Possible Cause B: Barrier gate controller failure.
Solution: Replace the controller.
DZE4 NonSpring Barrier Gate product image showing the straight boom design and installation
Tag:

manual barrier gate

safety barrier gate

car barrier gate
