Features

Specifications

Operating Time: 1.8s~6s

Boom Type: Straight Folding Fencing

Housing Material: Steel

Color: Gold

Application: Parking Lot

Warranty: 1 Year

Highlight:

5 Million+ Cycle Operating Life Non-Spring Barrier Gate

304 Stainless Steel Housing Boom Barrier Gate

Adjustable Speed 1.8s to 6s Parking Barrier Gate

Basic Infomation

Place of Origin: CHINA

Brand Name: WEJOIN

Certification: CE ISO SGS

Model Number: E40

Payment & Shipping Terms

Packaging Details: carton

Delivery Time: 3-5 working days

Payment Terms: T/T,Western Union

Supply Ability: 10000 sets/month

Gallery

5 Million+ Cycle Operating Life Non-Spring Barrier Gate Adjustable Speed 1.8s to 6s

Product Description

5 Million+ Cycle Operating Life Non-Spring Boom Barrier Gate for Basement Parking

6s running speed two fence boom length 4.5m non-spring barrier gate

Intelligent Barrier Types

Barrier Types	Description (Boom Length=L, Meters=M, Seconds=S)
Barrier gate with fence boom	Two-levels, L≤3M, up speed 4S Two-levels, L≤3.5M, up speed 5S Two-levels, L≤4.5M, up speed 6S Three-levels, L≤3M, up speed 5S Three-levels, L≤3.5M, up speed 6S

Boom Barrier Basic Features

Springless Mechanism for Reduced Mechanical Adjustment

E40Pro adopts the WEJOIN DZE4 non-spring mechanism, replacing the conventional spring-balancing structure. The springless design eliminates the need for regular spring tension adjustment and reduces maintenance related to traditional spring mechanisms. The mechanism is also designed as a modular assembly, making key components easier to inspect and replace when maintenance is required.

Adjustable Barrier Speed from 1.8 to 6 Seconds

The E40Pro supports an adjustable operating speed of 1.8 - 6 seconds, allowing the barrier gate to be configured according to different traffic conditions and project requirements. Instead of using one fixed operating speed for every application, installers can select a suitable speed based on factors such as:

Lane width
Traffic volume
Boom configuration
Vehicle access frequency
Site safety requirements

This makes E40Pro suitable for both general parking entrances and higher-frequency vehicle access points.

Multiple Boom Configurations

E40Pro supports several boom configurations to accommodate different lane layouts:

Up to 6 m straight boom
4.5 m two-section boom
4 m three-section boom
90° folding boom

Different boom structures can be selected according to available installation space and lane configuration. This flexibility is particularly useful for parking facilities and entrances where conventional straight-boom installation may be restricted by ceiling height or surrounding structures.

Three-Fence Boom Installation

Step 1. Fix the boom fixing plate on the boom with 2pcs of M12*70mm hexagon screw.

Step 2. Hold the fixing plate by hand, then lift up the boom vertically and install it on the boom holder. And then install the flat washer, spring washer, and M12 nut on the screw in turn, and fix the screw with a wrench.

Step 3. Fix the U-connecting unit to the cone axis on the barrier with the screw.

Step 4. Fix the bottom fence to the U-connecting unit, then release the 2pcs screw of the unit and adjust them to make the fence be perpendicular to the ground.
